Land Cruiser HR-1

Hydraulic Self-Unloading Electric Freight Tricycle

Max Payload 1,000 KG
Unloading System Hydraulic Tipping
Battery Options 72V 100Ah LiFePO₄
Range (Full Load) 80 – 100 KM
Certification CE / EEC / COC Ready
Ask for price
Contact now

Contact US

  • Whatsapp:(+86) 18254873362
  • Email:manager@qidiev.com
  • Working Hours:
  • UTC/GMT + 8
  • Mon-Fri  8:30 am – 18:00 pm
  • Sat.  8:30 am – 15:00 pm
  • Sun.  closed


    Facebook Instagram Tumblr Whatsapp
    1,000 KG
    Payload Capacity (Industry Leading)
    100 KM
    Full Load Range (Lithium Option)
    CE / EEC / DOT
    Import Ready (Zero Hassle)
    60% Lower Cost
    vs Diesel Operation (High ROI)

    Technical Comparison

    Land Cruiser HR-1 vs. Generic Competitor — Full Specification Breakdown

    Specification
    QIDI HR-1
    Generic Competitor
    Why It Matters
    ▎ Frame & Structure
    Frame Thickness
    3.0 mm Steel
    2.0 mm Steel
    50% stronger, no frame cracks under full load
    Cargo Box Material
    2.5mm Reinforced Plate
    1.2mm Thin Iron
    Anti-deformation, longer service life
    Cargo Box Size (L×W×H)
    1800×1100×480 mm
    1500×1000×400 mm
    20% more cargo volume per trip
    Wheelbase
    1950 mm
    1750 mm
    Better stability with heavy loads
    ▎ Powertrain & Electronics
    Motor Power
    1500W Brushless DC
    1000W Brushed
    50% more torque for hill climbing
    Controller (ECU)
    1500W / 60V Smart
    1000W / 48V Basic
    Smarter power distribution, less heat
    Battery Options
    72V 100Ah LiFePO₄
    48V 45Ah Lead-Acid
    3× cycle life, lighter weight
    Range (Full Load)
    80 – 100 KM
    40 – 50 KM
    Double the daily delivery radius
    Charging Time
    6 – 8 Hours
    8 – 10 Hours
    Faster turnaround, more trips/day
    ▎ Hydraulic & Unloading System
    Unloading System
    Hydraulic Dual-Cylinder
    Manual / Single Cylinder
    Tilt angle up to 45°, effortless dumping
    Max Tipping Angle
    45°
    25° – 30°
    Complete cargo discharge, no residue
    Hydraulic Pump Type
    Gear Pump (Self-Priming)
    Piston Pump (Manual)
    One-button operation, saves labor cost
    ▎ Braking & Safety
    Front Brake
    Hydraulic Disc
    Mechanical Drum
    Shorter stopping distance, safer
    Rear Brake
    Hydraulic Disc (Dual)
    Mechanical Drum
    Balanced braking under heavy load
    Parking Brake
    Yes (Hand Lever)
    No / Optional
    Secure hill parking, prevents rollaway
    ▎ Suspension & Wheels
    Front Suspension
    φ37 Spring Shock Absorber
    φ32 Basic Shock
    Better shock absorption on rough roads
    Rear Suspension
    Multi-Leaf Spring (5 pcs)
    Single Leaf / Rigid
    Handles bumpy loads without damage
    Tyre & Rim (Front/Rear)
    F/R 400-12 Steel Rim
    F/R 350-10 Plastic Rim
    Stronger rim, no cracks on heavy loads
    ▎ Load Capacity & Compliance
    Max Payload
    1,000 KG
    500 – 600 KG
    Nearly 2× the cargo per trip
    Max Speed
    35 – 40 KM/H
    25 – 30 KM/H
    Faster delivery, more orders/day
    Certification
    CE / EEC / COC Ready
    None / Self-Declared
    Legal import to EU & SEA markets
    Warranty Period
    2 Years
    6 – 12 Months
    Lower risk, lower long-term cost
    CKD Loading (40HQ)
    60 – 70 PCS
    40 – 50 PCS
    Lower sea freight cost per unit

    * Data based on industry averages for generic electric cargo tricycles. Actual performance may vary by terrain, load and operating conditions.

    Proven Worldwide

    Land Cruiser HR-1 in real-world operations across 3 continents.

    QIDI Land Cruiser HR-1 electric hydraulic dumping tricycle operating in German factory yard, handling industrial waste and materials for workplace transport
    🇩🇪 Germany / Europe
    Workplace Transport & Recycling

    DGUV-certified safety standards. Hydraulic dumping for effortless disposal of industrial waste, scrap materials and recyclables across manufacturing campuses.

    QIDI Land Cruiser HR-1 electric cargo tricycle navigating narrow alley in Jakarta Indonesia, delivering Shopee Lazada parcels through congested streets and monsoon floods
    🇮🇩 Indonesia / SE Asia
    Last-Mile Delivery in Jakarta

    IP67 waterproof motor conquers monsoon floods. 1000KG payload carries 3× more than motorcycles through narrow "Gang" alleys. The ultimate Shopee & Lazada fleet solution.

    QIDI Land Cruiser HR-1 heavy-duty electric tricycle hauling construction materials on unpaved rural road in Tanzania Africa, built for rough terrain and heavy loads
    🇹🇿 Tanzania / Africa
    Construction & Farm-to-Market

    Rugged durability for unpaved roads. Hydraulic tipping dumps gravel, sand and harvests in seconds. Solar panel option solves unreliable grid power. 50+ countries served.

    QIDI Land Cruiser HR-1 electric tricycle with hydraulic dump bed in warehouse logistics yard, transporting goods for urban distribution and retail replenishment
    🌍 Global Markets
    Warehouse & Retail Replenishment

    From Saudi Arabia to Brazil, the HR-1 adapts to local needs. Customizable cargo box, battery options and steering position for every market's unique requirements.

    50+
    Countries Served
    1,000 KG
    Payload Capacity
    2,500+
    Units Deployed Monthly
    24/7
    After-Sales Support

    OEM / ODM Customization Services

    Tailored solutions for global distributors — from small-batch trial orders to large-scale mass production.

    Body Configuration
    • Custom cargo box size (up to 2.2m length)
    • Hydraulic cylinder pressure adjustment
    • Optional rain canopy / enclosed cabin
    • Spare tire rack / tool box add-ons
    Powertrain Options
    • Motor power: 1000W–2000W brushless
    • Battery: Lead-acid / LiFePO₄ options
    • Voltage: 60V / 72V configurable
    • Controller: Smart programmable ECU
    Compliance Support
    • CE / EEC certification for EU markets
    • DOT compliance for North America
    • SONCAP for Nigeria / Africa
    • GCC certification for Middle East
    Brand Customization
    • Custom logo printing (body / seat / meter)
    • Exclusive color matching (Pantone code)
    • User manual / packaging branding
    • Private label exclusive model designs
    Streamlined Cooperation Process
    1. 1
      Requirement Consultation

      1–2 days

    2. 2
      Engineering Proposal

      3–5 days

    3. 3
      Sample Production

      15–20 days

    4. 4
      Mass Production

      25–30 days

    5. 5
      Shipping & After-Sales

      24/7 support

    10 Units
    Low MOQ for Trial Orders
    30 Days
    Fast Lead Time (Industry Avg: 45)
    $0
    Free Mold Fee for Repeat Orders
    2 Years
    Warranty & Lifetime Tech Support

    Trusted by 120+ distributors across 50+ countries — your reliable long-term manufacturing partner.

    Request Custom Quotation

    Globally Certified & Trusted

    Every Land Cruiser HR-1 meets international homologation standards for import-ready deployment.

    CE Certified
    EEC Compliant
    DOT Ready
    ISO 9001
    SONCAP
    CCC China
    50+
    Countries Served
    120+
    Active Distributors
    25,000+
    Units On The Road
    96%
    Repeat Order Rate

    What Our Partners Say

    Real feedback from fleet operators and distributors worldwide.

    "
    ★★★★★

    "The hydraulic dumping system alone saved us 3 labor hours per day. After 18 months of daily use in our Berlin warehouse, zero frame cracks and battery still holds 92% capacity."

    MK
    Logistik Berlin GmbH · 🇩🇪 Germany
    "
    ★★★★★

    "Jakarta's narrow alleys are no match for the HR-1. We replaced 8 motorcycles with 5 units and now move 3× more cargo per trip. The IP67 motor survived monsoon season flawlessly."

    AR
    Jakarta E-Commerce Alliance · 🇮🇩 Indonesia
    "
    ★★★★★

    "Our HR-1s haul sand and gravel on roads that would destroy a normal tricycle. The 3.0mm frame is no joke — after 2 years of abuse, they still tip at 45° without bending."

    JO
    Dar es Salaam Construction Co. · 🇹🇿 Tanzania

    Quality Certified, Trustworthy

    We are committed to quality management, compliance, and continuous improvement, ensuring our customers can buy with confidence.
